Trench MOS

Part Number	Download	Status	Circuit	Type	Process	ESD Yes/No	VDS V	VGS V	ID A	VGS(TH) V	RDS(mΩ)@VGS 10V Typ	RDS(mΩ)@VGS 10V Max	RDS(mΩ)@VGS 4.5V Typ	RDS(mΩ)@VGS 4.5V Max	Package
Reset Reset All		Active OK Reset		Dual-N N-ch P-ch Single-N Single-P OK Reset	Planar Trench OK Reset	No Yes OK Reset	OK Reset	±12 ±20 ±25 ±30 ±7 ±8 OK Reset	OK Reset	OK Reset	OK Reset	OK Reset	OK Reset	OK Reset	PDFN3.3×3.3-8L PDFN5×6-8L SOP8 SOT-23 SOT-23-6L SOT-323 SOT-363 SOT-523 SOT-723 TO-252-2L OK Reset

AD-CJ2303P		Active		Single-P	Trench	Yes	-30	±20	-1.9	-1~-3	75	190	115	330	SOT-23
AD-CJ2305P		Active		Single-P	Trench	Yes	-12	±8	-4.1	-0.5~-0.9			30	45	SOT-23
AD-CJ2307P		Active		Single-P	Trench	Yes	-30	±20	-2.7	-1~-3	73	88	110	138	SOT-23
AD-CJ2309AP		Active		Single-P	Trench	Yes	-60	±20	-2	-1~-2.5	130	190	180	240	SOT-23
AD-CJ2310P		Active		Single-N	Trench	Yes	60	±20	3	0.5~2	82	105	91	125	SOT-23
AD-CJ2312P		Active		Single-N	Trench	Yes	20	±8	5	0.45~1	-	-	18	31.8	SOT-23
AD-CJAB022SN04AH		Active		Single-N	Trench	No	40	±20	30	2.3 ~ 3.7	14.5	18	-	-	PDFN3.3×3.3-8L
AD-2SK3541		Active		Single-N	Trench	Yes	30	±20	0.1	0.8~1.5					SOT-723
AD-2N7002KDW		Active		Dual-N	Trench	Yes	60	±20	0.34	1.3	900	2500	1100	3000	SOT-363
AD-CJ3439KDW		Active		N-ch P-ch	Trench Trench	Yes Yes	20 -20	±12 ±12	0.75 -0.66	0.35~1.1 -0.35~-1.1	-	-	260 430	380 520	SOT-363
AD-BSS84		Active		Single-P	Trench	No	-50	±20	-0.13	-1.1~-2	4500	8000	-	-	SOT-23
AD-BSS84W		Active		Single-P	Trench	No	-50	±20	-0.13	-1.1~-2	4500	8000	-	-	SOT-323
AD-CJ3401		Active		Single-P	Trench	No	-30	±12	-4.2	-0.9	50	65	60	75	SOT-23
AD-CJ3401P		Active		Single-P	Trench	No	-30	±12	-4.2	-0.9	50	65	60	75	SOT-23
AD-CJ3407		Active		Single-P	Trench	No	-30	±20	-4.1	-1~-2.1	50	60	68	87	SOT-23
AD-CJ3407P		Active		Single-P	Trench	No	-30	±20	-4.1	-1~-2.1	50	60	68	87	SOT-23
AD-CJAN013P04AL		Active		Single-P	Trench	No	-40	±25	-50	-1~-2.5	8.5	13	10.5	18	PDFN5×6-8L
AD-CJAN35P03B		Active		Single-P	Trench	No	-30	±20	-50	-1~-2.5	9.5	14	12.4	18	PDFN5×6-8L
AD-CJAN8R0P04AL		Active		Single-P	Trench	No	-40	±25	-66	-1.3~-2.2	6.2	8	8.2	11.5	PDFN5×6-8L
AD-CJQ014P03AL		Active		Single-P	Trench	No	-30	±20	-12	-1~-2.5	11	14	16	24	SOP8

«
