Trench MOS

Part Number	Download	Circuit	Status	Type	Process	ESD Yes/No	VDS V	VGS V	ID A	VGS(TH) V	RDS(mΩ)@VGS 10V Typ	RDS(mΩ)@VGS 10V Max	RDS(mΩ)@VGS 4.5V Typ	RDS(mΩ)@VGS 4.5V Max	Package
Reset Reset All			Active OK Reset	Dual-N Dual-P N/P-ch Single-N Single-P OK Reset	Trench OK Reset	No Yes OK Reset	OK Reset	±10 ±12 ±16 ±20 ±25 ±30 ±6 ±7 ±8 OK Reset	OK Reset	-0.35~-1.1 -0.3~-1 -0.45~-1.2 -0.4~-0.9 -0.4~-1 -0.4~-1.0 -0.4~-1.3 -0.5~-0.9 -0.5~-1 -0.5~-1.2 -0.5~-1.5 -0.6~-1.4 -0.6~-1.5 -0.7 -0.7~-1.3 -0.9~-2 -1.0~-2.5 -1.0~-3.0 -1.1~-2.2 -1.2~-2.2 -1.5 -1.5~-2.5 -1.5~-3.5 -1~-2 -1~-2.5 -1~-3 -1～-2.5 -1～-3 -2~-4 0.35~1.1 0.35~1.4 0.35~2.5 0.3~1.1 0.45~1 0.45~1.1 0.45~1.2 0.4~1 0.4~1.0 0.4~1.1 0.4~1.2 0.4~1.4 0.5~0.9 0.5~1 0.5~1.1 0.5~1.2 0.5~1.3 0.5~1.5 0.5~2 0.5～2 0.65~1.2 0.65~1.20 0.6~1 0.6~1.2 0.6~1.4 0.6~1.5 0.7~1.4 0.7~1.5 0.7~3 0.8~1.5 0.8~3 0.9~1.5 1 1.0~2.5 1.2~2.5 1.2~2.8 1.2～3 1.3~2.3 1.3~2.5 1.5 1.5~2.5 1~2 1~2.5 1~2.8 1~3 1～2.2 1～2.5 1～3 2~4 OK Reset	OK Reset	OK Reset	OK Reset	OK Reset	CSPB1111-4 CSPB1313-4 CSPB1515-4 CSPB1717-4 CSPB1912-6 CSPB2213-6 CSPB2217-6 CSPC2019-10 CSPC2115-10 CSPC2623-10 CSPC2624-10 CSPC3015-10 CSPC3028-14 CSPC3030-14 CSPC3220-10 CSPC3421-10 DFN1006-3L DFN1006-3L-A DFNWB2x2-6L DFNWB2x3-6L DFNWB3x3-8L DFNWB5x2-6L PDFNWB3.3x3.3-8L PDFNWB3.3x3.3-8L-B PDFNWB5x6-8L PDFNWB5x6-8L-A SOP8 SOT-223 SOT-23 SOT-23-3L SOT-23-6L SOT-323 SOT-363 SOT-523 SOT-563 SOT-723 SOT-89-3L TO-220-3L-C TO-252-2L TO-92 TSSOP8 WBFBP-03E OK Reset

CJQ4407A			Active	Single-P	Trench	No	-30	±20	-11	-1.2~-2.2	10.5	14	11.5	16	SOP8
CJQ4435A			Active	Single-P	Trench	No	-30	±20	-9.9	-1.1~-2.2	13	17	17	24	SOP8
CJA10P06MX			Active	Single-P	Trench	No	-60	±20	-10	-1.0~-2.5	58	75	75	110	SOT-89-3L
CJA01N65MX			Active	Single-N	Trench	No	650	±30	0.5	0.5~1.5	26000	30000	27000	30000	SOT-89-3L
CJBB7002K			Active	Single-N	Trench	Yes	60	±20	0.41	1.3~2.3	1200	1500	1300	1800	DFN1006-3L-A
CJAB50N02S			Active	Single-N	Trench	Yes	18	±12	50	0.4~1.0	-	-	2.8	3.2	PDFNWB3.3x3.3-8L
CJ13024SP			Active	Dual-N	Trench	Yes	12	±8	9	0.4~1.4	-	-	4.7	5.4	CSPB1912-6
CJMN3010S			Active	Single-N	Trench	Yes	30	±10	10	0.45~1	-	-	9.5	14	DFNWB2x2-6L
CJAB013P04A			Active	Single-P	Trench	No	-40	±25	-50	-1.0~-2.5	8.5	13	10.5	18	PDFNWB3.3x3.3-8L
CJU30P10A			Active	Single-P	Trench	No	-100	±20	-30	-1.0~-2.5	45	55	50	70	TO-252-2L
CJAB25P03A			Active	Single-P	Trench	No	-30	±20	-25	-1.0~-3.0	13	20	17	30	PDFNWB3.3x3.3-8L
2N7002A			Active	Single-N	Trench	No	60	±20	0.45	1.0~2.5	500	750	-	-	SOT-23
CJ3139KA			Active	Single-P	Trench	Yes	-20	±10	-0.66	-0.35~-1.1	-	-	330	450	SOT-23
CJ3134KA			Active	Single-N	Trench	Yes	20	±12	0.9	0.4~1.1	-	-	110	170	SOT-23
CJAC1214M03			Active	N/P-ch	Trench Trench	No No	30 -30	±20 ±20	30 -30	1~2.5 -1~-2.5	6.8 11	12 15	8.3 15	16 25	PDFNWB5x6-8L-A
CJA05N06			Active	Single-N	Trench	No	60	±20	5.5	0.5~2	72	105	83	125	SOT-89-3L
CJ8820			Active	Single-N	Trench	Yes	20	±12	7	0.5~1.1	16.7	21	18.7	24	SOT-23
CJ8810			Active	Single-N	Trench	Yes	20	±12	7	0.4~1	15.5	26	16	27	SOT-23
2SK3018S			Active	Single-N	Trench	No	30	±20	0.5	0.8~1.5	-	-	-	-	SOT-23
2SK3018S			Active	Single-N	Trench	No	30	±20	0.5	0.8~1.5	-	-	-	-	SOT-323

«
