Trench MOS

Part Number	Download	Circuit	Status	Type	Process	ESD Yes/No	VDS V	VGS V	ID A	VGS(TH) V	RDS(mΩ)@VGS 10V Typ	RDS(mΩ)@VGS 10V Max	RDS(mΩ)@VGS 4.5V Typ	RDS(mΩ)@VGS 4.5V Max	Package
Reset Reset All			Active OK Reset	Dual-N Dual-P N/P-ch Single-N Single-P OK Reset	Trench OK Reset	No Yes OK Reset	OK Reset	±10 ±12 ±16 ±20 ±25 ±30 ±6 ±7 ±8 OK Reset	OK Reset	-0.35~-1.1 -0.3~-1 -0.45~-1.2 -0.4~-0.9 -0.4~-1 -0.4~-1.0 -0.4~-1.3 -0.5~-0.9 -0.5~-1 -0.5~-1.2 -0.5~-1.5 -0.6~-1.4 -0.6~-1.5 -0.7 -0.7~-1.3 -0.9~-2 -1.0~-2.5 -1.0~-3.0 -1.1~-2.2 -1.2~-2.2 -1.5 -1.5~-2.5 -1.5~-3.5 -1~-2 -1~-2.5 -1~-3 -1～-2.5 -1～-3 -2~-4 0.35~1.1 0.35~1.4 0.35~2.5 0.3~1.1 0.45~1 0.45~1.1 0.45~1.2 0.4~1 0.4~1.0 0.4~1.1 0.4~1.2 0.4~1.4 0.5~0.9 0.5~1 0.5~1.1 0.5~1.2 0.5~1.3 0.5~1.5 0.5~2 0.5～2 0.65~1.2 0.65~1.20 0.6~1 0.6~1.2 0.6~1.4 0.6~1.5 0.7~1.4 0.7~1.5 0.7~3 0.8~1.5 0.8~3 0.9~1.5 1 1.0~2.5 1.2~2.5 1.2~2.8 1.2～3 1.3~2.3 1.3~2.5 1.5 1.5~2.5 1~2 1~2.5 1~2.8 1~3 1～2.2 1～2.5 1～3 2~4 OK Reset	OK Reset	OK Reset	OK Reset	OK Reset	CSPB1111-4 CSPB1313-4 CSPB1515-4 CSPB1717-4 CSPB1912-6 CSPB2213-6 CSPB2217-6 CSPC2019-10 CSPC2115-10 CSPC2623-10 CSPC2624-10 CSPC3015-10 CSPC3028-14 CSPC3030-14 CSPC3220-10 CSPC3421-10 DFN1006-3L DFN1006-3L-A DFNWB2x2-6L DFNWB2x3-6L DFNWB3x3-8L DFNWB5x2-6L PDFNWB3.3x3.3-8L PDFNWB3.3x3.3-8L-B PDFNWB5x6-8L PDFNWB5x6-8L-A SOP8 SOT-223 SOT-23 SOT-23-3L SOT-23-6L SOT-323 SOT-363 SOT-523 SOT-563 SOT-723 SOT-89-3L TO-220-3L-C TO-252-2L TO-92 TSSOP8 WBFBP-03E OK Reset

CJQ2040M04			Active	N/P-ch	Trench Trench	No No	40 -40	±20 ±20	6 -4	1~2.5 -1~-3	15 30	21 45	21 40	29 60	SOP8
CJND2004S			Active	Single-N	Trench	Yes	18	±12	10	0.4~1.1	-	-	8.9	11.6	DFNWB5x2-6L
CJAB35P03B			Active	Single-P	Trench	No	-30	±20	-35	-1~-2.5	9	14	12.5	24	PDFNWB3.3x3.3-8L
CJAB25N04A			Active	Single-N	Trench	No	40	±20	25	1~2.5	6.6	8.5	8.5	12	PDFNWB3.3x3.3-8L
2SK3019S			Active	Single-N	Trench	No	30	±20	0.5	0.8~1.5	-	-	-	-	SOT-523
CJS8810A			Active	Dual-N	Trench	Yes	20	±10	7	0.4~1	13.6	17.7	14.5	18.9	TSSOP8
CJCD2007A			Active	Dual-N	Trench	Yes	20	±10	8	0.4~1	10.5	13.7	11.3	14.7	DFNWB2x3-6L
CJQ4459A			Active	Single-P	Trench	No	-30	±20	-6	-1~-2.5	28	36	40	52	SOP8
CJ2301A			Active	Single-P	Trench	No	-20	±8	-2.3	-0.4~-1	-	-	82	112	SOT-23
CJQ20N03B			Active	Single-N	Trench	No	30	±20	20	1~2.5	3.5	4.5	4.3	6.5	SOP8
CJAC70N03S			Active	Single-N	Trench	No	30	±20	70	1~2.5	4.8	6	6.5	9.5	PDFNWB5x6-8L
CJMN3010L			Active	Single-N	Trench	Yes	30	±10	10	0.45~1	-	-	8.3	14	DFNWB2x2-6L
CJ2204			Active	Single-P	Trench	No	-20	±12	-2.8	-0.4~-1.3	-	-	29	40	SOT-23
CJAC50P03S			Active	Single-P	Trench	No	-30	±20	-50	-1~-2.5	6.5	8.2	8.4	12	PDFNWB5x6-8L
CJAB65N03L			Active	Single-N	Trench	No	30	±20	65	1~2.5	2.5	3.2	3.6	5	PDFNWB3.3x3.3-8L
CJAC80N03L			Active	Single-N	Trench	No	30	±20	80	1~2.5	2.7	3.5	4	6	PDFNWB5x6-8L
CJBA3139KB			Active	Single-P	Trench	Yes	-20	±12	-0.66	-0.35~-1.1	-	-	165	520	DFN1006-3L
CJQ4406A			Active	Single-N	Trench	No	30	±20	10	1~3	8.3	10.8	10.8	15	SOP8
CJL8810A			Active	Dual-N	Trench	Yes	20	±12	7	0.4~1	12	15.5	12.8	16.6	SOT-23-6L
CJBA7002KL			Active	Single-N	Trench	Yes	60	±20	0.34	1~2.5	-	3500	-	4000	DFN1006-3L

«
